Accsoon CineView Master 4K SDI/HDMI Wireless Video Transmission System
What's Included: 1 x Transmitter 1 x Receiver 2 x Npf750 Battery 1 x Shoe Mount 1 x HDMI Cable 1 x Carrying Case Package Price: 1 Day: $80 | 3 Day: $120 | 5 Day: $145 | 7 Day: $165 | 10 Day: $210 | 14 Day: $250 | To Rent: Please type in 'Accsoon CineView Master' in our rental form
Inputs / Outputs
Video I/O
Transmitter: 1x HDMI 2.0 Input Transmitter: 1x HDMI 2.0 Output Transmitter: 1x BNC (3G-SDI) Input Transmitter: 1x USB-C (Unspecified Signal) Output Receiver: 1x HDMI 2.0 Output Receiver: 1x BNC (3G-SDI) Output
Embedded Audio
HDMI/SDI
Audio I/O
No
Power I/O
Transmitter/Receiver: 1x Barrel Input
Wireless
Wireless Range
1.6 Miles / 2.5 km (Line-of-Sight)
# of Channels
20
Frequency Range
2412 to 2472 MHz 5180 to 5580 MHz 5660 to 5825 MHz
Latency
35 ms
RF Power
17 dBm
Wi-Fi
Wi-Fi 6 (802.11ax); Tri-Band (2.4 & 5 + 5 GHz)
Bluetooth
No
Mobile App Compatible
Yes: Android & iOS App Name: Accsoon SEE
Cellular Support
No
Format Support
Video Format
HDMI UHD 4K: 60/50/30/25/24 1080p: 60/50/30/25/24 1080i: 60/59.94/50 SDI 1080p: 60/50/30/25/24 1080i: 60/59.94/50
Audio Format
Not Specified by Manufacturer
Timecode Support
No
Power
Input Power
7.4 to 16.8 VDC
Battery Type
Transmitter/Receiver: 1x L-Series
Mounting
Mounting
Transmitter/Receiver: 1/4"-20 Female (Bottom)
General
Status Display
Transmitter/Receiver: LCD
Environmental Resistance
No
Operating Conditions
14 to 104°F / -10 to 40°C
Dimensions
Transmitter/Receiver: 5.1 x 3.7 x 1.3" / 130 x 95 x 32 mm (Excluding Antenna)
Weight
Transmitter: 11.4 oz / 322.00 g, Excluding Antenna Receiver: 11.3 oz / 320.00 g, Excluding Antenna
One of the most notable features of the new CineView Master 4K is the ability to send a true 4K video signal with up to 60fps wirelessly. It supports one wired connection and four wireless connections, so there can be a total of five devices for monitoring.
Accsoon CineView Master 4K. Image Credit: CineD
The 4K signal is being handled by the CineView’s HDMI ports. There is also 3G-SDI, but that is limited to a 1080p resolution. The transmitter (TX) unit has an HDMI in, HDMI loop out, one SDI port, and a USB-C output. The receiver (RX) unit features HDMI out and SDI out.
The maximum range is around 2.5km/1.5 miles (unobstructed line of sight), according to Accsoon. This is thanks to the new, more powerful processor and Accsoon’s RTMS 4.0 video transmission protocol. As Nissy told us, the CineView Master 4K has a latency of approximately 25ms when transmitting 1080p and around 35ms when transmitting 4K.
In addition to HDMI and 3G-SDI, the device now features a USB-C video output port, too. This enables the integration of a SeeMo 4K into the system and the use of an iPhone or iPad for image monitoring. Through this port, CineView Master 4K can also provide power for the connected device.
