Yamaha DBR10 10" 700W Active PA Loudspeaker

Drivers

LF Driver	1x 10" / 25.4 cm Woofer Voice Coil: 2" / 5.1 cm Magnet: Ferrite
HF Driver	1x 1" / 25 mm Compression Driver Magnet: Ferrite

Performance

Frequency Range/Response	55 Hz to 20 kHz (-10 dB)
Maximum SPL	129 dB SPL
Coverage Angle	90° H x 60° V

Signal Processing

Crossover Frequency	2100 Hz
EQ & Filters	No
Alignment Delay	No
Digital Signal Processing	No

Connectivity

Audio I/O	2x Combo XLR-1/4" TRS Input 1x Stereo 2RCA Line Input 1x XLR 3-Pin Output
Network I/O	No
USB I/O	No
Wireless	No
Mobile App Compatible	No

Power

AC Input Power	100 to 120 VAC, 50 / 60 Hz
AC Power I/O	1x IEC Input
Power Consumption	60 W (1/8 Power) 18 W (Idle)

Physical

Color	Black
Mounting	Stand Mount 1 x 1.38" / 35 mm Pole Socket (Bottom) Suspension Points 2 x M8 Fly Point (Bottom)
Handles	1x Top
Construction Material	Plastic
Environmental Resistance	No
Dimensions	12.1 x 19.4 x 11.4" / 308 x 493 x 289 mm
Weight	23.2 lb / 10.5 kg

Giving you the flexibility of using it for floor monitoring, front of house, or rigged applications, the DBR10- 10" 2-Way Powered Loudspeaker from Yamaha is capable of up to 700W of dynamic output via its Class D amplifier. The loudspeaker features a 10" woofer and a 1" high-frequency driver and provides a maximum output of 129 dB. An on-board 2-channel mixers allows you to connect microphone or line level sources via 1/4", XLR, and RCA connectors. Thanks to its ergonomic handle and lightweight design the DBR10 is portable and can be easily transported.

High-Efficiency Class D Amplifier

The DBR10's lightweight, high performance Class-D amplifier is capable of producing up to 700W of power, achieving an SPL of 129 dB, delivered with clarity and dynamic characteristics

Custom Designed Transducer

The woofer delivers defined, powerful bass with minimal distortion, while the 1" precision compression driver produces accurate mid-range and high frequencies

Portable Cabinet

DBR Series speakers feature a compact, lightweight, and durable plastic cabinet which offers the portability of all Yamaha powered speakers. The sleek steel grille bolsters cabinet durability and protects the internal components while an ergonomic handles provide transportation and system setup

Enclosure Design for Floor Monitoring

DBR Series speakers feature an optimized 50° wedge angle for floor monitoring

On-Board 2-Channel Mixer

DBR Series speakers have two input channels. Channel 1 has a combo jack which accepts both XLR and TRS Phone allowing for either Mic or Line level input signals. Channel 2 offers two input options; a combo jack that accepts XLR or TRS Phone, and a stereo RCA pin jack for input from CD players or other stereo line-level sources. The onboard mixer allows you to select either Channel 1 + 2 MIX to mix the signal of Channel 1 and Channel 2, or Channel 1 THRU to pass the signal from Channel 1 only
